Pages: 1 [2] 3 4 ... 10
 11
 on: 2016-06-25 17:37:37
Started by Hydroque - Last post by ziozio
So where's your latest code then? Can we take a peek?

 12
 on: 2016-06-25 16:58:42
Started by CopyableCougar4 - Last post by CopyableCougar4
So I realized that I was only factoring in the bind pose matrix and not the animated matrix, but everything is still looking distorted. Since much of the code works fine until the model is animated, I *think* I can narrow down my problem to a few snippets.

They can be found here: http://pastebin.java-gaming.org/cf0c4276d4313

Also, in case this is relevant, this is how I determine the initial positions to send to the shader:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
for (int idx = 0; idx < submesh.getVertices().length; idx++) {
         com.digiturtle.md5.skeleton.Vertex vertex = submesh.getVertices()[idx];
         AnimatedVertex animatedVertex = new AnimatedVertex();
         Vector3f position = new Vector3f().zero();
         Vector3f normal = new Vector3f().zero();
         Vector2f textureCoords = new Vector2f().zero();
         float[] boneWeightsArray = { 0, 0, 0, 0 };
         float[] boneIndicesArray = { 0, 0, 0, 0 };
         Vector3f tmpPos = new Vector3f(), tmpPos2 = new Vector3f();
         textureCoords.set(vertex.getTextureCoords());
         for (int j = 0; j < 4 && j < vertex.getWeightCount(); j++) {
            // position += (joint_position + (joint_orientation * weight_position)) * weight_bias
            Weight weight = submesh.getWeights().get(vertex.getStartWeight() + j);
            Joint joint = skeleton.getJoints().get(weight.getJointIndex());
            tmpPos.set(weight.getPosition()).rotate(joint.getLocalTransform().getOrientation());
            tmpPos2.set(tmpPos).add(joint.getLocalTransform().getTranslation()).mul(weight.getWeightBias());
            position.add(tmpPos2);
            boneIndicesArray[j] = (float) weight.getJointIndex();
            boneWeightsArray[j] = weight.getWeightBias();
         }
         animatedVertex.setPosition(position.x, position.y, position.z);
         animatedVertex.setNormal(normal.x, normal.y, normal.z);
         animatedVertex.setTextureCoord(textureCoords.x, textureCoords.y);
         animatedVertex.setBoneWeights(boneWeightsArray[0], boneWeightsArray[1], boneWeightsArray[2], boneWeightsArray[3]);
         animatedVertex.setBoneIndices(boneIndicesArray[0], boneIndicesArray[1], boneIndicesArray[2], boneIndicesArray[3]);
         geometry.put(animatedVertex.getData());
      }


 13
 on: 2016-06-25 16:24:21
Started by shadowstryker - Last post by theagentd
And they also do texture atlases. So you got 1154 * texture and limited by units and ram.
No, the whole point of texture arrays is to NOT have texture atlases, as they don't handle filtering well (individual textures bleed together). Texture arrays do not have that problem.

 14
 on: 2016-06-25 14:49:02
Started by TritonDreyja - Last post by TritonDreyja
Lol just wait till I add bears lol.
Tbh the bunny was a homeage to Terraria. I mean it's only what motivated me to make something myself.

Thanks ags1, the art style and look were an experiment for me, and they seem to be fitting Tongue

 15
 on: 2016-06-25 14:33:03
Started by TritonDreyja - Last post by ags1
I watched the video, it's not my kind of game but it looks very smooth and elegant.

 16
 on: 2016-06-25 14:31:06
Started by TritonDreyja - Last post by Hydroque
Terraria has bunnies. Lol

 17
 on: 2016-06-25 13:52:50
Started by TritonDreyja - Last post by TritonDreyja
You added a bunny lol
The bunny isn't what's important, It's the fact that the Mob superclass is working properly. Now I can just spit out mobs
as long as i have graphics. Minus the crazy flying ones that shoot projectiles though.

 18
 on: 2016-06-25 11:13:34
Started by TritonDreyja - Last post by Hydroque
Also, the enemies won't be zombies and skeletons like all those other sandbox games... I really am wondering why someone hasn't broken the trend Tongue
You added a bunny lol

 19
 on: 2016-06-25 06:31:55
Started by CopyableCougar4 - Last post by Stranger
Hi.

I worked few years ago on the same problem.
I post fragments of my code. Maybe this will help.

Joint.java

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
public class Joint implements NamedObject
{
    public final int NULL_PARENT = -1;

    private final short parentIndex;
    private final String name;
    private final Vector3f bindTranslation;
    private final Quaternion4f bindRotation;
    private final Tuple3f bindScale;

    private final Matrix4f invBindPoseMatrix;

    private short index;
    private boolean isAux;

    public final boolean hasParent()
    {
        return ( index > 0 );
    }

    public final void calcInvBindPoseMatrix( Joint parent )
    {
        Matrix4f m = Matrix4f.fromPool();

        MathUtils.compose( bindTranslation, bindRotation, bindScale, m );
        invBindPoseMatrix.invert( m );
        if( parent != null )
        {
            invBindPoseMatrix.mul( invBindPoseMatrix, parent.getInvBindPoseMatrix() );
        }

        Matrix4f.toPool( m );
    }
    public Joint( String name, short index, Joint parent, Transform bindTransform, boolean isAux )
    {
        this.parentIndex = parent == null ? NULL_PARENT : parent.getIndex();
        this.name = name;
        this.index = index;
        bindTranslation = bindTransform.getTranslation( null ).getReadOnly();
        bindRotation = bindTransform.getRotation( null ).getReadOnly();
        bindScale = bindTransform.getScale( null ).getReadOnly();

        invBindPoseMatrix = new Matrix4f();
        calcInvBindPoseMatrix( parent );
        this.isAux=isAux;
    }

    public Joint( Joint joint, Joint parent )
    {
        this.parentIndex = parent == null ? NULL_PARENT : parent.getIndex();
        name = joint.name;
        index = joint.index;

        bindTranslation = joint.bindTranslation;
        bindRotation = joint.bindRotation;
        bindScale = joint.bindScale;

        invBindPoseMatrix = joint.invBindPoseMatrix;
    }
}


SkinnedMeshUpdater.java

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
public class SkinnedMeshUpdater
{
    private static Map<Skeleton, SkinnedMeshUpdater> skeletonToUpdater = new HashMap<Skeleton, SkinnedMeshUpdater>();
    private final Skeleton skeleton;
    private final Shape3D[] shapes;

    private final float[][] weights;
    private final short[][] jointIndices;

    private float[][] bindPoseCoords;
    private float[][] bindPoseNormals;

    private final int[] influencesPerVertex;

    private final Vector3f[] worldTranslations;
    private final Quaternion4f[] worldRotations;
    private final Tuple3f[] worldScales;

    private Matrix4f[] matrixPalette;

    public Skeleton getSkeleton()
    {
        return skeleton;
    }

    public Shape3D[] getTarget()
    {
        return shapes;
    }

    public float[][] getWeights()
    {
        return weights;
    }

    public short[][] getJointIndices()
    {
        return jointIndices;
    }

    public int[] getInfluencesPerVertex()
    {
        return influencesPerVertex;
    }

    public static SkinnedMeshUpdater create( Skeleton skeleton,
                                             Shape3D[] target,
                                             float[][] weights,
                                             short[][] jointIndices,
                                             int[] influencesPerVertex )
    {
        SkinnedMeshUpdater smu = skeletonToUpdater.get( skeleton );
        if( smu == null )
        {
            smu = new SkinnedMeshUpdater( skeleton, target, weights, jointIndices, influencesPerVertex );
        }

        return ( smu );
    }

    public void update( IAnimationData data )
    {
        if( data == null )
        {
            return;
        }
        updateSkeleton( data );
        for( int i = 0; i < shapes.length; i++ )
        {
            updateGeometry( i );
        }
    }

    private void updateSkeleton( IAnimationData data )
    {
        SkeletalKeyFrame pose = ( SkeletalKeyFrame ) data;
        Skeleton skeleton = pose.getSkeleton();
        for( int i = 0, jc = skeleton.getJointsCount(); i < jc; i++ )
        {
            Joint joint = skeleton.getJoint( i );
            setAbsolutes( joint, pose );
            short ji = joint.getIndex();
            if( joint.isAux() )
            {
                matrixPalette[ ji ].setIdentity();
            }
            else
            {
                mul( joint.getInvBindPoseMatrix(),
                        worldTranslations[ ji ],
                        worldRotations[ ji ],
                        worldScales[ ji ],

                        matrixPalette[ ji ]
                );
            }
        }
    }

    private void updateGeometry( int shapeIdx )
    {
        Shape3D shape = shapes[ shapeIdx ];
        Geometry geom = shape.getGeometry();
        float[] bindPoseCoords = this.bindPoseCoords[ shapeIdx ];
        float[] bindPoseNormals = this.bindPoseNormals[ shapeIdx ];
        int influencesPerVertex = this.influencesPerVertex[ shapeIdx ];
        float[] weights = this.weights[ shapeIdx ];
        short[] jointIndices = this.jointIndices[ shapeIdx ];

        float x, y, z;
        float nX = 0, nY = 0, nZ = 0;
        float vSumX, vSumY, vSumZ;
        float nSumX, nSumY, nSumZ;
        float tmpX, tmpY, tmpZ;

        for( int i = 0; i < geom.getVertexCount(); i++ )
        {
            x = bindPoseCoords[ i * 3 ];
            y = bindPoseCoords[ i * 3 + 1 ];
            z = bindPoseCoords[ i * 3 + 2 ];
            if( geom.hasNormals() )
            {
                nX = bindPoseNormals[ i * 3 ];
                nY = bindPoseNormals[ i * 3 + 1 ];
                nZ = bindPoseNormals[ i * 3 + 2 ];
            }
            vSumX = 0f;
            vSumY = 0f;
            vSumZ = 0f;

            nSumX = 0f;
            nSumY = 0f;
            nSumZ = 0f;

            float wSum = 0f;
            float weight;
            for( int j = 0; j < influencesPerVertex; j++ )
            {
                if( j != influencesPerVertex - 1 )
                {
                    weight = weights[ i * ( influencesPerVertex - 1 ) + j ];
                    wSum += weight;
                }
                else
                {
                    weight = 1 - wSum;
                }
                if( weight == 0f )
                {
                    continue;
                }
                final int jointIndex = jointIndices[ i * influencesPerVertex + j ];
                if( jointIndex == 0 )
                {
                    JAGTLog.debug( "jindex=0, influencesPerVertex=", influencesPerVertex );
                }
                Matrix4f m = matrixPalette[ jointIndex ];
                //vertices
                tmpX = m.m00() * x + m.m01() * y + m.m02() * z + m.m03();
                tmpY = m.m10() * x + m.m11() * y + m.m12() * z + m.m13();
                tmpZ = m.m20() * x + m.m21() * y + m.m22() * z + m.m23();

                vSumX += tmpX * weight;
                vSumY += tmpY * weight;
                vSumZ += tmpZ * weight;

                //normals
                if( geom.hasNormals() )
                {
                    tmpX = m.m00() * nX + m.m01() * nY + m.m02() * nZ;
                    tmpY = m.m10() * nX + m.m11() * nY + m.m12() * nZ;
                    tmpZ = m.m20() * nX + m.m21() * nY + m.m22() * nZ;

                    nSumX += tmpX * weight;
                    nSumY += tmpY * weight;
                    nSumZ += tmpZ * weight;
                }
            }

            geom.setCoordinateWithoutOpenGlHandling( i, vSumX, vSumY, vSumZ );
            if( geom.hasNormals() )
            {
                geom.setNormalWithoutOpenGlHandling( i, nSumX, nSumY, nSumZ );
            }
        }
        geom.setBoundsDirty();
        geom.getOpenGLReference_DL_GeomData().invalidateNames();
        geom.getOpenGLReference_DL().invalidateNames();

        shape.updateBounds( false );
    }

    private static void mul( Matrix4f matrix, Vector3f translation, Quaternion4f rotation, Tuple3f scale, Matrix4f out )
    {
        //out.set( matrix );
        Matrix4f tmp = Matrix4f.fromPool();

        tmp.setIdentity();
        tmp.setTranslation( translation );
        out.set( tmp );

        tmp.set( rotation );
        out.mul( tmp );

        tmp.setIdentity();
        tmp.m00( scale.getX() );
        tmp.m11( scale.getY() );
        tmp.m22( scale.getZ() );
        out.mul( tmp );

        out.mul( matrix/* , out */ );

        Matrix4f.toPool( tmp );
    }

    //doesn't work  when non-uniform scales
    private void setAbsolutes( Joint joint, SkeletalKeyFrame frame )
    {
        if( joint.hasParent() )
        {
            short parentIndex = joint.getParentIndex();
            short localIndex = joint.getIndex();
            MathUtils.mul(
                    worldTranslations[ parentIndex ],
                    worldRotations[ parentIndex ],
                    worldScales[ parentIndex ],

                    frame.getTranslations()[ localIndex ],
                    frame.getRotations()[ localIndex ],
                    frame.getScales()[ localIndex ],

                    worldTranslations[ localIndex ],
                    worldRotations[ localIndex ],
                    worldScales[ localIndex ]
            );
        }
        else
        {
            short localIndex = joint.getIndex();
            worldTranslations[ localIndex ].set( frame.getTranslations()[ localIndex ] );
            worldRotations[ localIndex ].set( frame.getRotations()[ localIndex ] );
            worldScales[ localIndex ].set( frame.getScales()[ localIndex ] );
        }
    }

    public SkinnedMeshUpdater( Skeleton skeleton, Shape3D[] target, float[][] weights, short[][] jointIndices, int[] influencesPerVertex )
    {
        this.skeleton = skeleton;
        this.shapes = target;
        this.weights = weights;
        this.jointIndices = jointIndices;
        this.influencesPerVertex = influencesPerVertex;

        worldTranslations = new Vector3f[ skeleton.getJointsCount() ];
        worldRotations = new Quaternion4f[ skeleton.getJointsCount() ];
        worldScales = new Tuple3f[ skeleton.getJointsCount() ];
        matrixPalette = new Matrix4f[ skeleton.getJointsCount() ];

        for( int i = 0; i < worldTranslations.length; i++ )
        {
            worldTranslations[ i ] = new Vector3f();
            worldRotations[ i ] = new Quaternion4f();
            worldScales[ i ] = new Tuple3f();
            matrixPalette[ i ] = new Matrix4f();
        }

        bindPoseCoords = new float[ target.length ][];
        bindPoseNormals = new float[ target.length ][];

        for( int i = 0; i < target.length; i++ )
        {
            int numVertices = target[ i ].getGeometry().getVertexCount();
            Geometry geom = target[ i ].getGeometry();
            bindPoseCoords[ i ] = new float[ numVertices * 3 ];
            geom.getCoordinates( 0, bindPoseCoords[ i ] );
            if( geom.hasNormals() )
            {
                bindPoseNormals[ i ] = new float[ numVertices * 3 ];
                geom.getNormals( 0, bindPoseNormals[ i ] );
            }
        }
    }
}


 20
 on: 2016-06-25 04:10:26
Started by TritonDreyja - Last post by TritonDreyja
So this is cool but how is it going to be different / better from Terraria? Also, it's very slow on my computer.. and my computer is no slouch.

The latest available download is from a year ago... that explains the performance lol. The new port is way easier on the graphics card, and made my PC perform this at ridiculous framerates, so your problems will be fixed with the next release Smiley

Other than that, this game will be different (idk about better) than Terraria because this game will highlight RPG elements. It will have a storyline that requires mob grinding and stat managing to complete. It will have interactions, conversations and outcomes based on quests and stuff. The 3 underground biomes will be really original and they will not dissapoint any player, I promise you that Wink

Other than that, I'll still have pride in saying I created everything for this game. Soundtrack, graphics, programming, ideas, all of it is from me. And in my mind, that is what will really make it great.

Also, the enemies won't be zombies and skeletons like all those other sandbox games... I really am wondering why someone hasn't broken the trend Tongue

Pages: 1 [2] 3 4 ... 10

CopyableCougar4 (13 views)
2016-06-25 16:56:52

Hydroque (51 views)
2016-06-22 02:17:53

SwampChicken (52 views)
2016-06-20 13:22:57

SwampChicken (52 views)
2016-06-20 13:22:49

SwampChicken (48 views)
2016-06-20 13:22:26

Hydroque (89 views)
2016-06-15 08:22:50

Hydroque (81 views)
2016-06-13 06:40:55

DarkCart (199 views)
2016-05-29 02:30:33

Hydroque (168 views)
2016-05-26 14:45:46

Mac70 (171 views)
2016-05-24 21:16:33
Making a Dynamic Plugin System
by Hydroque
2016-06-25 00:13:25

Java Data structures
by BinaryMonkL
2016-06-13 21:22:09

Java Data structures
by BinaryMonkL
2016-06-13 21:20:42

FPS Camera Tutorial
by Hydroque
2016-05-22 05:40:58

Website offering 3D Models specifically for games for free
by vusman
2016-05-18 17:23:09

Website offering 3D Models specifically for games for free
by vusman
2016-05-09 08:50:56

Website offering 3D Models specifically for games for free
by vusman
2016-05-06 11:10:21

Website offering 3D Models specifically for games for free
by vusman
2016-04-29 12:56:17
java-gaming.org is not responsible for the content posted by its members, including references to external websites, and other references that may or may not have a relation with our primarily gaming and game production oriented community. inquiries and complaints can be sent via email to the info‑account of the company managing the website of java‑gaming.org
Powered by MySQL Powered by PHP Powered by SMF 1.1.18 | SMF © 2013, Simple Machines | Managed by Enhanced Four Valid XHTML 1.0! Valid CSS!
